12-Bay Xeon® 3.3GHz Quad-Core CPU NAS – XN8012RE

  • With High performance and expansion by using 12Gb/s technology, maximum space up to 3.3PB.
  • Unified Storage-Integrated storage system supports block and file storage simultaneously and following protocols,
    iSCSI, CIFS, NFS, FTP, and AFP.
  • Universal and Efficient Data Backup-XMirror supports permission backup , disaster recovery and flexible protection
    between multiple NAS devices.
  • KVM Built-in Hypervisor Manager : enabling user to create and manage virtual machines that run directly on the
    XCubeNAS and host multiple virtualized environments without the additional hardware investment.
  • Comprehensive Data Security – Pool Military level encryption with AES-256, Write Once Read Many (WORM) , SelfEncrypting Drive (SED).
  • Thin Provision- Precision Restore and dynamically Space.
  • Advanced Enterprise Storage Technology-Auto-Tiering, Inline Compression, Deduplication and Thin Provision.
Compare

Reviews

There are no reviews yet.


Be the first to review “12-Bay Xeon® 3.3GHz Quad-Core CPU NAS – XN8012RE”

Ultra-high Performance and Virtualization Ready

The Industry’s first 2U hybrid NAS with Intel® Xeon ® E3 Quad-core processor provides native auto-tiering storage
capability to fulfill the maximum performance and high-capacity demand for enterprises. With up to 64GB memory
capacity, the XN8012RE’s maximum sequential write performance is up to 4,716MB/s and 4K sequential IOPS is up to
359,790. This is the best choice for enterprise data storage applications, virtualization ready storage and data backup
systems.

Hardware Specifications

Architecture All-in-one
Storage OS QSM Specification Details
CPU
Processor Intel® Xeon®
CPU Architecture 64-bit
CPU Frequency Quad-Core 3.3GHzz
Memory
System Flash 8GB USB DOM
Memory Module Pre-installed 8GB DDR4 U-DIMM
Total Memory Slots 4
Memory Expandable up to 64 GB
Notes
Storage
Drive Bays 3.5″ Slot x 12
Maximum Drive Bays with Expansion Unit 204
Compatible Drive Type 3.5″ SATA HDD

2.5″ SATA HDD

2.5″ SATA SSD

Drive Interface SATA 6Gb/s
(backward compatible with SATA 3Gb/s)
Maximum Internal Raw Capacity 240TB
Maximum Raw Capacity with Expansion Units 8,400TB
Hot Swappable Drive
Notes
  • For more information, please refer to compatibility matrix and hardware manual
  • Maximum internal raw capacity= Max HDD capacity x 12
  • Capacity may vary by RAID types
External Port
USB 2.0 Port 1 (Front)
USB 3.0 Port 4 (Rear)
HDMI Port 1
Others Console Port x1
Notes
Connectivity Port
1GbE RJ45 LAN Port 4 (Onboard)
10GbE RJ45 LAN Port 2 (Option)
10GbE SFP+ LAN Port 2 (Option)
Thunderbolt 3 2 (Option)
16Gb SFP+ Fibre Channel
Notes For more information, please refer to accessory book

Please refer to the section below for expansion slot specification

Expansion Port
12Gb/s SAS Wide Port 2 (Option)
Notes For more information, please refer to accessory book
PCIe Expansion
Gen3x8 Slot 1
Gen3x4 Slot 1
Notes For more information, please refer to hardware manual
Host Card Expansion
Gen3x8 Slot
Gen2x4 Slot
Notes
Appearance
Dimension (H x W x ;D) (mm) 88.5 x 438 x 510
Chassis Form Factor 19″ Rackmount 2U 12 Bay
Net Weight (kg) 13.5
Gross Weight (kg) 14.9
Notes
Memory Protection
Cache-to-Flash Module
Battery Backup Module + Flash Module
Notes
Others
System Fan 60mm x 60mm x 3 pcs
Replaceable System Fan
Power Recovery
Scheduled Power On/Off
Wake on LAN/WAN
Power Supply Unit / Adapter 250W x2
Redundant Power Supply
AC Input Power Voltage 100V-240V
Power Frequency 50-60 Hz, Single Phase
Power Consumption 332 W (Access)
179 W (HDD Hibernation)
British Thermal Unit 1132 BTU/hr (Access)
611 BTU/hr (HDD Hibernation)
LCM Support
Notes
Environment Temperature
Operating Temperature 0 to 40°C
Storage Temperature -10°C to 50°C
Operating Relative Humidity 20% to 80% non-condensing
Non-operating Relative Humidity 10% to 90%
Notes
Certification
Certifications CE

FCC

BSMI

VCCI

RCM

SASO

EAC

Notes
Warranty
Standard Warranty 3 years
