Gigabit 802.3af/at PoE Injector – 60W (Suitable for FCS-4042) – POI-5001
• Auto-detection and protection of non-standard PoE devices IEEE 802.3af/at PoE compliant to simplify deployment and installation Total PoE power budget: 60W, up to 60W per port
• Auto-detection and protection of non-standard PoE devices
• IEEE 802.3af/at PoE compliant to simplify deployment and installation
• Total PoE power budget: up to 60W
- Overview
- Specification
POI-5001 is a single port, high-power 60W PoE PSE solution for remote PoE PD devices. Generating up to 60W through 8 pins, POI-5001 supplies remote power for new applications such as wireless access points, pan-tilt-zoom (PTZ) IP cameras, lighting, panel display for digital signage and video-phones. It complies to IEEE 802.3bt PoE++ standards to deliver 60W on both end-point and midspan pairs with a total power of 60W PoE output. It can work with 10/100Base-T networking devices and emerging 1000Base-T devices such as Wi-MAX and wireless IEEE 802.11n access points.
Operating temperature | 0°C ~ 40°C |
Indicators | Power, Mode A, Mode B |
Power output | 56VDC |
Standards | IEEE 802.3at/af |
Features | 1-port GigE Ultra PoE Injector |
Product weight (kg) | 0,53 |
Color | Black |
EAN | 4015867199466 |
Model Number | POI-5001 |
Package contents | POI-5001 Stromkabel |
802.3af/at PoE | 1 |
Grade | Commercial |
Data Rate | Gigabit Ethernet |
Data rate | 10/100/1000Mbps |
Power consumption | Less than 2W |
Dimensions (W x D x H) | 180 x 71 x 37 mm |
