Bring interactive technology to workplace so the company have more effective meeting. It is equipped with state of the edge software for interactive meeting and trainings.
• Collaborative Wiring and faster response time
• Write and Control from the connected SMART devices over the Wireless Network.
• 4K resolution, high contrast and 2 Hi-Fi speakers makes it very ideal for commercial display purposes
• Wirelessly Connect 4 devices concurrently and can control Laptop and PC using
• Bundled with an Interactive Whiteboard Software that contains hundreds of training/teaching materials from different subjects.
• Upgraded Configuration can bring users excellent video conference experience, and can effectively integrate control, flexible and fast.
| Features | 86 inch IFP | 75 inch IFP | 65 inch IFP |
|---|---|---|---|
| Technology | IR Touch | IR Touch | IR Touch |
| Display Size | 86″ TFT LCD Module with DLED Backlight | 75″ TFT LCD Module with DLED Backlight | 65″ TFT LCD Module with DLED Backlight |
| Display Area | 1895.0(H) x 1106.0 (V) | 1665.66(H) x 994.73 (V) | 1428.4 (H) x 803.5 (V) |
| Resolution | 3840*2160 pixels ([email protected]) | 3840*2160 pixels ([email protected]) | 3840*2160 pixels ([email protected]) |
| Aspect Ratio | (16:9) | (16:9) | (16:9) |
| Contrast Ratio | (4000:1) | (4000:1) | (4000:1) |
| Brightness | 400cd/m2 | 400cd/m2 | 400cd/m2 |
| Panel Bit/Colors | 1.07G colors (8-bit+FRC). | 1.07G colors (8-bit+FRC). | 1.07G colors (8-bit+FRC). |
| Viewing Angles | 178 degree | 178 degree | 178 degree |
| Touch Power Input | 5V USB2.0 | 5V USB2.0 | 5V USB2.0 |
| Touch Resolution | 32767*32767 | 32767*32767 | 32767*32767 |
| Bezel Thickness | 18mm | 18mm | 18mm |
| Panel Dimension | 1943.4*97.5*1166 | 1692.1 *97.5*1021.9 | 1470.9 *97.5* 897.5 |
| Gross Weight (kg±2) | 98 Kgs | 63 Kgs | 52 Kgs |
| Net Weight (kg±2) | 68 Kgs | 50 Kgs | 42 Kgs |
| Glass Surface | 4mm Mohs7 Anti-glare glass | 4mm Mohs7 Anti-glare glass | 4mm Mohs7 Anti-glare glass |
| Response Time | ≤10ms | ≤10ms | ≤10ms |
| Touch Points | 10 points on Android / 40 Points on Windows | 10 points on Android / 40 Points on Windows | 10 points on Android / 40 Points on Windows |
| Android OS Support | Android 8.0 64bit | Android 8.0 64bit | Android 8.0 64bit |
| CPU | Dual-core A73 and dual-core A53, 1.5GHz | Dual-core A73 and dual-core A53, 1.5GHz | Dual-core A73 and dual-core A53, 1.5GHz |
| GPU | Quad-core MaliG51 | Quad-core MaliG51 | Quad-core MaliG51 |
| RAM Type and Size | 4GB DDR4 | 4GB DDR4 | 4GB DDR4 |
| Flash Type and Size | 32GB | 32GB | 32GB |
| Touch Life Time | Unlimited | Unlimited | Unlimited |
| Output Ports | LAN OUT RJ45 *1, LAN IN RJ45 * 1, RS232(TYPE-DB9) *1, USB2.0 (TYPE-A) *2, USB3.0 OTG (5GB/S)*1 , AUDIO IN *1, SPDIF * 1 , TOUCH INPUT USB2.0 (TYPE B) *3, DP IN*1, HDMI IN (2.0)*2, HDMI OUT (2.0) *1 , Type C *1 | LAN OUT RJ45 *1, LAN IN RJ45 * 1, RS232(TYPE-DB9) *1, USB2.0 (TYPE-A) *2, USB3.0 OTG (5GB/S)*1 , AUDIO IN *1, SPDIF * 1 , TOUCH INPUT USB2.0 (TYPE B) *3, DP IN*1, HDMI IN (2.0)*2, HDMI OUT (2.0) *1 , Type C *1 | LAN OUT RJ45 *1, LAN IN RJ45 * 1, RS232(TYPE-DB9) *1, USB2.0 (TYPE-A) *2, USB3.0 OTG (5GB/S)*1 , AUDIO IN *1, SPDIF * 1 , TOUCH INPUT USB2.0 (TYPE B) *3, DP IN*1, HDMI IN (2.0)*2, HDMI OUT (2.0) *1 , Type C *1 |
| Type and RJ-45 Ethernet Port | Available in the android board | Available in the android board | Available in the android board |
| Blutooth Supports | YES | YES | YES |
| Wi-Fi Support (a/b/g/n/ac or any other) | WIFI dongle | WIFI dongle | WIFI dongle |
| Speakers | 2 X 15W | 2 X 15W | 2 X 15W |
| Digital Signage Software | Required | Required | Required |
| Accessories Included | |||
| Power | 100-240V AC (50/60 Hz) | 100-240V AC (50/60 Hz) | 100-240V AC (50/60 Hz) |
| Stand by Mode | <_0.5W | <_0.5W | <_0.5W |
| Power Consumption | <500W | <500W | <500W |
| VESA standard | 800×600 | 600×400 | 600×400 |
