16-Bay Intel® Xeon® 2.2GHz Quad-Core CPU with Built-in 10GbE solution – XN8016R

• With High performance and expansion by using 12Gb/s technology, maximum space up to 3.3PB.
• Standard 10GbE LAN (RJ45) x 2, 12Gb/s SAS wide port x 2.
• Full modularized design – The main components including controller, power supply and fan module can be easily
replaced and upgraded.
• Fully redundant PSU (80 PLUS Platinum).
• Standard 8GB memory and maximum memory capacity support up to 128GB.
• Unified Storage-Integrated storage system supports block and file storage simultaneously and following protocols,
iSCSI, CIFS, NFS, FTP, WebDAV, 16G double-port fiber channel and AFP.
• Universal and Efficient Data Backup-XMirror supports permission backup , disaster recovery and flexible protection
between multiple NAS devices.
• Comprehensive Data Security – Pool Military level encryption with AES-256, Write Once Read Many (WORM) , SelfEncrypting Drive (SED).
• Advanced Enterprise Storage Technology-Auto-Tiering, Inline Compression, Deduplication.

Compare

Reviews

There are no reviews yet.


Be the first to review “16-Bay Intel® Xeon® 2.2GHz Quad-Core CPU with Built-in 10GbE solution – XN8016R”

Ultra-high Performance and Virtualization Ready

With Intel® Pentium® D dual-core processor, built-in 10GbE network ports and SAS wide ports, the XN8016R provides
maximum sequential write performance of up to 2,357MB/s and 4K IOPS 183,107. . Connecting with expansion units, the
XN8016 can install up to 208 disks, which brings the storage capacity support up to 3.3 PB. Fully modularized design
makes major components easily to replace and upgrade. The unify storage design brings the device to support file
storage, iSCSI and Fiber channel, which is the best choice for multi-functional data processing and data center on SMEs.

Hardware Specifications

Architecture Single Controller
Storage OS QSM Specification Details
CPU
Processor Intel® Xeon®
CPU Architecture 64-bit
CPU Frequency Quad-Core 2.2GHz (8-core processor models are also available; Model: XN8016R_8C)
Memory
System Flash 8GB SATA DOM
Memory Module Pre-installed 8GB DDR4 ECC U-DIMM
Total Memory Slots 4
Memory Expandable up to 128 GB
Notes
Storage
Drive Bays 3.5″ Slot x 16
Maximum Drive Bays with Expansion Unit 424
Compatible Drive Type 3.5″ SAS HDD

3.5″ SATA HDD

2.5″ SAS SSD

2.5″ SATA HDD

2.5″ SATA SSD

Drive Interface SAS 12Gb/s and SATA 6Gb/s
(backward compatible with SAS 6Gb/s and SATA 3Gb/s)
Maximum Internal Raw Capacity 320TB
Maximum Raw Capacity with Expansion Units 8,480TB
Hot Swappable Drive
Notes
  • For more information, please refer to compatibility matrix and hardware manual
  • Maximum internal raw capacity= Max HDD capacity x 16
  • Capacity may vary by RAID types
External Port
USB 2.0 Port 1 (Front)
USB 3.0 Port 2 (Rear)
HDMI Port
Others Console Port x1
Notes
Connectivity Port
1GbE RJ45 LAN Port 1 (Onboard)
4 (Option: HQ-01G4T)
10GbE RJ45 LAN Port 2 (Onboard)
2 (Option: HQ-10G2T)
10GbE SFP+ LAN Port 4 (Option: HQ-10G4S2)
25GbE SFP28 LAN Port 2 iSCSI (Option: RHCE25P2)​
Thunderbolt 3
16Gb SFP+ Fibre Channel 4 (Option: HQ-16F4S2)
2 (Option: HQ-16F2S2)
Notes For more information, please refer to accessory book

Please refer to the section below for expansion slot specification

Expansion Port
12Gb/s SAS Wide Port 2 (Onboard)
Notes
PCIe Expansion
Gen3x8 Slot
Gen3x4 Slot
Notes
Host Card Expansion
Gen3x8 Slot 1
Gen2x4 Slot 1
Notes Gen2x4 slot provides 20Gb bandwidth
Appearance
Dimension (H x W x D) (mm) 130.3 x 438 x 515
Chassis Form Factor 19″ Rackmount 3U 16 Bay
Net Weight (kg) 21.7
Gross Weight (kg) 29.1
Notes
Memory Protection
Cache-to-Flash Module
Battery Backup Module + Flash Module
Notes
Others
System Fan 80mm x 80mm x 4 pcs
Replaceable System Fan
Power Recovery
Scheduled Power On/Off
Wake on LAN/WAN
Power Supply Unit / Adapter 770W/850W x 2 (80 PLUS Platinum)
Redundant Power Supply
AC Input Power Voltage 100V-240V
Power Frequency 50-60 Hz, Single Phase
Power Consumption 203 W (Access)
200 W (HDD Hibernation)
British Thermal Unit 692 BTU/hr (Access)
681 BTU/hr (HDD Hibernation)
LCM Support
Notes
Environment Temperature
Operating Temperature 0 to 40°C
Storage Temperature -10°C to 50°C
Operating Relative Humidity 20% to 80% non-condensing
Non-operating Relative Humidity 10% to 90%
Notes
Certification
Certifications CE

FCC

BSMI

VCCI

SASO

EAC

RCM

Notes
Warranty
Standard Warranty 3 years
Notes
