Gigabit 802.3af/at PoE Injector – 30W (Suitable for FCS-4051) – POI-3000
• IEEE 802.3af/at PoE PSE with 30W power budget
• Auto-detection and protection of non-standard PoE devices
• Unique interlocking feature for easy installation
• 10/100/1000Mbps wire speed transmission and reception
• 6KV surge protection level on each port
- Overview
- Specification
Advanced PoE SolutionThe LevelOne POI-3000 is a single port, high power PoE PSE solution for remote PoE PD devices. Generating up to 30W , POI-3000 supplies remote power for new applications such as wireless access points, pan-tilt-zoom (PTZ) IP cameras and videophones. It complies with IEEE 802.3at PoE standard and is backward to IEEE802.3af. It can work with 10/100Base-T networking devices and emerging 1000Base-T devices such as Wi-MAX and wireless IEEE 802.11n access points. For all the function featured in POI-3000, people can get the benefit of flexible network installation at lower cost, less downtime. It also provides a high-bandwidth pipe to the network.
| Operating humidity | 5% RH ~ 95% RH |
|---|---|
| Operating temperature | 0°C ~ 70°C |
| Indicators | Power, PoE |
| Mount | Wall mount |
| Pin assignment and polarity | 1/2 (+), 3/6 (-) |
| Standards | IEEE 802.3 10Base-T, Ethernet IEEE 802.3u 100Base-TX, Fast Ethernet IEEE802.3ab 1000Base-T, Gigabit Ethernet IEEE 802.3af/at Power over Ethernet (PoE) compliant |
| Features | Output Power Voltage: 52 VDC Maximal Per Port Power: 30 Watts Maximal Input Power AC Input Voltage: 100~240 VAC Requirements AC Input Current: 0.8A@ 100-240 VAC |
| Product weight (kg) | 0,28 |
| Color | Black |
| EAN | 4015867158111 |
| Model Number | POI-3000 |
| Package contents | POI-3000 Quick Installation Guide |
| Gigabit RJ45 | 2 |
| 802.3af/at PoE | 1 |
| Grade | Commercial |
| Data Rate | Gigabit Ethernet |
| Data rate | 10/100/1000Mbps |
| Power consumption | 30W |
| Dimensions (W x D x H) | 55 x 35.5 x 173.5 mm |
