25X Optical Zoom Outdoor PTZ Camera (without Mounting Kit) – FCS-4051
• Built-in infrared LEDs for night viewing up to 100m
• Built-in Micro SD/SDHC card slot for local storage
• Dual power support: 12V DC/PoE (IEEE 802.3at)
• Video compression: H.265, H.264, MJPEG
• Weatherproof IP66-rated housing
• Supports 25X optical zoom
• Simultaneous Third Streams
• Free surveillance and CMS (Central Management System) software packages with 64-channel license
- Overview
- Specification
The LevelOne FCS-4051 is a PTZ IP surveillance camera designed for use outdoors, boasting 2-Megapixel resolution and a 25X optical zoom. The camera features motorized Pan and Tilt features as well, enabling it to focus in a variety of directions and zoom in on a specific viewing area. The camera is also PoE, enabling it to run both power and data on the one Cat.5 cable, making deployments easy and efficient. An IP66-rated weatherproof casing allows for safe, reliable operation in outdoor conditions such as rain, heat, dust, snow and humidity.
| Approval and compliance | CE/FCC/UL,/IP66/RoHS UL (UL 62368-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 62368-1:2014+A11:2017); BIS (IS 13252 (Part1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)TVS 6000V lightning protection, surge protection and voltage transient protection |
| Compatibility | Onvif Version 19.12, Profile S, Profile G, Profile T Simultaneous Live View: Up to 20 channels Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS 1.3, host authentication (MAC address) |
| Supported browsers | Edge |
| Compatible operating systems | Windows 10 |
| Operating humidity | 0% RH ~ 90% RH |
| Operating temperature | -30°C ~ 65°C |
| Angle of View (°) | Horizontal field of view: 57.6° to 2.5° (wide-tele), Vertical field of view: 34.4° to 1.4° (wide-tele), Diagonal field of view: 64.5° to 2.9° (wide-tele) |
| Audio format | G.711/G.722.1/G.726/MP2L2/PCM |
| Digital zoom | 16x |
| Image sensor | 1/2.8″ progressive scan CMOS |
| Indicators | Power |
| IR cut filter | Yes |
| IR range | Up to 100 meter |
| Lens | 4.8 mm to 120 mm, F1.6 |
| Minimum illumination (lux) | Color: 0.005 Lux @ (F1.6, AGC ON); B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Mount | Wall mount |
| Optical zoom | 25X |
| Pan (Swivel) range | 360° |
| Power supply | 12V/2A |
| Resolution | Main Stream: 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720) Sub-Stream: 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240) Third Stream: 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Shutter time | 1s to 1/30,000 s |
| Storage capacity | Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB |
| Standards | IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| Tilt range | Tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s |
| Video format | H.265/H.264/MJPEG |
| Weatherproof rating | IP66 |
| Features | Digital Wide Dynamic Range (DWDR),rotate mode. Brightness, contrast, saturation, and sharpness are adjustable via web browser.3 Stream,SDK
Detects up to 5 faces simultaneously. Line crossing, intrusion, region entrance, region exiting |
| Product weight (kg) | 2 |
| Color | White |
| EAN | 4015867227596 |
| Model Number | FCS-4051 |
| Package contents | FCS-4051 Screw Kit Power adapter Quick Installation Guide Resource CD (User Manual, Utility, QIG) |
| Camera Type | Speed Dome |
| Resistance | Weatherproof |
| Zoom Type | Motorization |
| 2-way Audio | Yes |
| DI/DO | Yes |
| IR Leds for night vision | Yes |
| PoE Supported | Yes |
| Max. Resolution | 2 Megapixels |
| IP Camera series | GEMINI |
| Dimensions (W x D x H) | 295 x 164.5 x 164.5 mm |
