64-Channel NVR Supported with RAID(0,1,5,10) and H.265 – NVR-0764
• Free CMS (Central Management System) software with 64-channel license
• Supports PTZ/preset point/preset sequence
• Supports video resolutions up to 12 megapixels
• Video compression: H.265, H.264, MPEG4
• Supports 4k2k HDMI local display
- Overview
- Specification
The LevelOne NVR-0764 NVR enables live view, recording and playback for up to 64 IP network cameras at the same time, featuring up to 12-megapixel resolution and H.264/H.265 video compression. Operation is easy and intuitive via the web browser interface (IE), enabling remote monitoring and functionality. 8 HDD bays complete the package, with a disk capacity of up to 10TB making the LevelOne NVR-0764 a powerful, smart and cost-effective solution for managing your security network.Supports dual gigabit LAN ports allowing for concurrent dual-connection, and providing a network backup in case of unscheduled network downtime.Central Management System (CMS) software is included for free, with no license fees. The CMS is capable of managing up to 256 NVRs, making it suitable for large scale surveillance applications.
Approval and compliance | CE,FCC,UL |
Supported browsers | IE 9.0 above |
Operating humidity | 10% RH ~ 90% RH |
Operating temperature | -10°C ~ 55°C |
Embedded system | Lunix |
Bandwidth | Incoming bandwidth: 320 Mbps,or 200 Mbps (when RAID is enabled) Outgoing bandwidth:256 Mbps, or 200 Mbps (when RAID is enabled) |
Hard drive capacity | Max. support up to 10TB for each HDD |
Indicators | Power |
Resolution | Recording resolution: 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF,Live view / Playback Resolution: 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF Synchronous playback:16-ch Decoding format : H.265/H.264/MPEG4 Capability: 4-ch @4K, or 16-ch @ 1080p |
Storage capacity | 8 SATA interfaces for 8 HDDs (HDD Not included) |
Standards | TCP,UDP,IPv4,IPv6,Http,Https,SMTP,NTP,SNTP,RTSP, SNMP, FTP, DHCP, DDNS, PPPoE, SSL, RTP |
Number of video channel | 64 |
Video format | H.265/H.264/H.264+/MPEG4 |
Features | Support RAID 0,1,5,10 Pre-Recording / Post-Recording Search Date / Time / Event Export video by USB / Web browser / CMS Liveview & Playback on Smart phone iOS, Android |
Product weight (kg) | 10 |
Color | Black |
EAN | 4015867206416 |
Model Number | NVR-0764 |
Package contents | NVR-0764 Ressource CD (Bedienungsanleitung, Hilfsprogramm, 64-Kanal Verwaltungssoftware) Stromkabel |
Max. Channels | 64 |
Max. HDD Bay | 8 |
RAID supported | Yes |
Dimensions (W x D x H) | 470 x 90 x 445 mm |
