32-Channel NVR supported H.264+ and 6MP Resolution – NVR-0437

• Free CMS (Central Management System) software with 64-channel license

• 4 x 3.5 HDD bays support disk capacity of up to 6TB

• Supports video resolutions up to 6 megapixels

• Display mode: Live view/playback/full screen

• Supports smart camera search and 2-way audio

• Supports PTZ/preset point/preset sequence

Compare Compare

The LevelOne NVR-0437 NVR enables live view, recording and playback for up to 32 IP network cameras at the same time, featuring up to 6-megapixel resolution and H.264/H.264+ video compression. Operation is easy and intuitive via the web browser interface (IE), enabling remote monitoring and functionality. Mobile device operations are also supported (iOS/Android), with remote viewing via the LevelOne NVR app. The NVR also features built-in HDMI, VGA and USB ports for peripheral devices such as a monitor, mouse or keyboard, allowing users to operate directly from the NVR without the cost of adding a PC to the deployment. 4 HDD bays complete the package, with a disk capacity of up to 6TB making the LevelOne NVR-0437 a powerful, smart and cost-effective solution for managing your security network.Supports dual gigabit LAN ports allowing for concurrent dual-connection, and providing a network backup in case of unscheduled network downtime.Central Management System (CMS) software is included for free, with no license fees. The CMS is capable of managing up to 256 NVRs, making it suitable for large scale surveillance applications.

Approval and compliance CE/FCC,uL
Supported browsers Internet Explorer 9.0 or above
Operating humidity 10% RH ~ 90% RH
Operating temperature -10°C ~ 55°C
Embedded system Lunix
Bandwidth Outgoing bandwidth 80Mbps incoming bandwidth 160Mbps
Hard drive capacity 4 SATA interfaces for 4 HDDs Up to 6TB capacity for each HDD
Indicators Power
Ready
Status
Alarm
HDD
TxRx
Resolution Record Up to 6-Megapixel resolution
Storage capacity 4 SATA interfaces for 4 HDDs Up to 6TB capacity for each HDD
Number of video channel 32
Video format H.264/H264+
Features Include 16 port PoE (IEEE 802.3 af/at) Total 200 Watt
Outgoing bandwidth 80Mbps
incoming bandwidth 160Mbps
Product weight (kg) 3
Color Black
EAN 4015867201800
Model Number NVR-0437
Package contents NVR-0437
Stromkabel
Ressource CD (Bedienungsanleitung, QIG)
RJ45-Ethernet-Kabel
Max. Channels 32
Max. HDD Bay 4
RAID supported No
Dimensions (W x D x H) 390 x 440 x 69 mm
