32-Channel NVR supported H.264+ and 6MP Resolution – NVR-0437
• Free CMS (Central Management System) software with 64-channel license
• 4 x 3.5 HDD bays support disk capacity of up to 6TB
• Supports video resolutions up to 6 megapixels
• Display mode: Live view/playback/full screen
• Supports smart camera search and 2-way audio
• Supports PTZ/preset point/preset sequence
- Overview
- Specification
The LevelOne NVR-0437 NVR enables live view, recording and playback for up to 32 IP network cameras at the same time, featuring up to 6-megapixel resolution and H.264/H.264+ video compression. Operation is easy and intuitive via the web browser interface (IE), enabling remote monitoring and functionality. Mobile device operations are also supported (iOS/Android), with remote viewing via the LevelOne NVR app. The NVR also features built-in HDMI, VGA and USB ports for peripheral devices such as a monitor, mouse or keyboard, allowing users to operate directly from the NVR without the cost of adding a PC to the deployment. 4 HDD bays complete the package, with a disk capacity of up to 6TB making the LevelOne NVR-0437 a powerful, smart and cost-effective solution for managing your security network.Supports dual gigabit LAN ports allowing for concurrent dual-connection, and providing a network backup in case of unscheduled network downtime.Central Management System (CMS) software is included for free, with no license fees. The CMS is capable of managing up to 256 NVRs, making it suitable for large scale surveillance applications.
Approval and compliance | CE/FCC,uL |
Supported browsers | Internet Explorer 9.0 or above |
Operating humidity | 10% RH ~ 90% RH |
Operating temperature | -10°C ~ 55°C |
Embedded system | Lunix |
Bandwidth | Outgoing bandwidth 80Mbps incoming bandwidth 160Mbps |
Hard drive capacity | 4 SATA interfaces for 4 HDDs Up to 6TB capacity for each HDD |
Indicators | Power Ready Status Alarm HDD TxRx |
Resolution | Record Up to 6-Megapixel resolution |
Storage capacity | 4 SATA interfaces for 4 HDDs Up to 6TB capacity for each HDD |
Number of video channel | 32 |
Video format | H.264/H264+ |
Features | Include 16 port PoE (IEEE 802.3 af/at) Total 200 Watt Outgoing bandwidth 80Mbps incoming bandwidth 160Mbps |
Product weight (kg) | 3 |
Color | Black |
EAN | 4015867201800 |
Model Number | NVR-0437 |
Package contents | NVR-0437 Stromkabel Ressource CD (Bedienungsanleitung, QIG) RJ45-Ethernet-Kabel |
Max. Channels | 32 |
Max. HDD Bay | 4 |
RAID supported | No |
Dimensions (W x D x H) | 390 x 440 x 69 mm |
